QUICKTRONIC DE LUXE HF DIM T8 Fluorescent Electronic Gear

Unavailable

Nominal voltage 230240 V
Operating frequency 40100 kHz
Mains frequency 5060 Hz
Input voltage DC 154276 V
Width 30.0 mm
Height 30.0 mm
Wire preparation length, input side 8.011 mm
Dimmable Yes
Dimming interface 110 V
Dimming range 1100 %
Approval marks approval VDE / E1 approval / VDE-EMC
EEI Energy Label A1
▼ see full specification ▼

Ask for product Description / FAQ / Warranty

Score

rate product

Description / FAQ Warranty

Electrical data
Nominal voltage	230240 V
Operating frequency	40100 kHz
Mains frequency	5060 Hz
Input voltage DC	154276 V
Dimensions & weight
Width	30.0 mm
Height	30.0 mm
Wire preparation length, input side	8.011 mm
Capabilities
Dimmable	Yes
Dimming interface	110 V
Dimming range	1100 %
Certificates & standards
Approval marks approval	VDE / E1 approval / VDE-EMC
EEI Energy Label	A1
Protection class	I

Product benefits

Same luminous flux with direct and alternating current
Automatic restart after lamp replacement

Areas of application

Suitable for use in emergency lighting systems as per EN 50172/DIN VDE 0108-100
Suitable for luminaires of protection class I

Product features

Control via 1…10 V interface
Supply voltage: 230…240 V
Line frequency: 0 Hz | 50 Hz | 60 Hz
Line voltage: 198…264 V
Dimming range: 1…100 % luminous flux
Automatic shutdown of defective lamps and at end of life (EoL)
Energy Efficiency Index EEI: A1
Safety: to EN 61347-2-3
