CV Power supplies 24V LED Power Supplies LED Power Supplies for Strips

Nominal current: 0.08 A Inrush current: 15 A  Max. no. of ECGs on circuit breaker 10 A: 30 Galvanic isolation primary/secondary: 3 kV Max. no. of ECGs on circuit breaker 16 A: 48 Surge capability (L-N): 1 kV Width: 50.0 mm Height: 22.0 mm Cable cross-section, input side: 1.0 mm² Product weight: 73.00 g Cable cross-section, output side: 1.0 mm² Casing material: Plastic Wire preparation length, input side: 10 mm Ambient temperature range: -20…+50 °C Maximum temperature at tc test point: 70 °C Temperature range at storage: -40…85 °C ECG lifetime: 50000 h  Max.housing temperature in case of fault: 100 °C Suitable for fixtures with prot. class: II Overheating protection: Automatic reversible Max. cable length to lamp/LED module: 10 m No-load proof: Yes Overload protection: Automatic reversible Short-circuit protection: Automatic reversible Approval marks – approval: CE / VDE / ENEC 10 Standards: Acc. to IEC 61347-2-13/Acc. to IEC 62384/Acc. to EN 55015/Acc. to IEC 61000-3-2/Acc. to IEC 61000-3-3/Acc. to IEC 61547 Type of protection: IP65 « hide more

Max. no. of ECGs on circuit breaker 10 A: 12 Galvanic isolation primary/secondary: 3.75 kV  Max. no. of ECGs on circuit breaker 16 A: 19 Surge capability (L-N): 2 kV Width: 40.0 mm Height: 16.0 mm Cable cross-section, input side: 0.75…1.5 mm²  Product weight: 290.00 g Cable cross-section, output side: 0.5…1.5 mm²  Casing material: Plastic Wire preparation length, input side: 10 mm Ambient temperature range: -20…+45 °C Maximum temperature at tc test point: 95 °C Temperature range at storage: -30…85 °C ECG lifetime: 50000 h  Max.housing temperature in case of fault: 110 °C Suitable for fixtures with prot. class: II Max. cable length to lamp/LED module: 10 m Approval marks – approval: CE / ENEC 10 / CB / C-Tick Standards: Acc. to IEC 61347-1/Acc. to IEC 61347-2-13/Acc. to IEC 62384/Acc. to CISPR 15/Acc. to IEC 61000-3-2/Acc. to IEC 61547 Type of protection: IP20 « hide more

Max. no. of ECGs on circuit breaker 10 A: 7 Galvanic isolation primary/secondary: 3 kV  Surge capability (L-N): 1 kV Width: 47.0 mm Height: 44.0 mm Cable cross-section, input side: 0.75…1.5 mm²  Product weight: 290.00 g Cable cross-section, output side: 0.5…1.5 mm²  Casing material: Plastic Wire preparation length, input side: 6.0 mm Ambient temperature range: -20…+50 °C Maximum temperature at tc test point: 80 °C Temperature range at storage: -40…85 °C ECG lifetime: 50000 h  Max.housing temperature in case of fault: 110 °C Suitable for fixtures with prot. class: II Max. cable length to lamp/LED module: 10 m Approval marks – approval: CE / ENEC 10 / VDE / VDE-EMC / GOST / C-Tick Standards: Acc. to IEC 61347-2-13/Acc. to IEC 62384/Acc. to EN 55015/Acc. to IEC 61000-3-2/Acc. to EN 61000-3-3/Acc. to EN 61547 Type of protection: IP20 « hide more
